stauff Heavy series hydraulic pipe clamp

Stauff heavy series hydraulic pipe clamp DIN3015 supplier

Structure:assembly including cover plate, weld plate, clamp body,hexagon bolts

Sizes:Rang of O.D. 6mm  to 406mm

Working Temperature
PP -30 degree up to +90 degree in dark green color
PA -40 degree up to +120 degree in dark color

AL -50°C up to +300°C Natural color
Q235 -80°C up to +500°C Galvanizing or parkerising
SUS304 or SUS316 -80°C up to +500°C Natural color

Stauff heavy series hydraulic pipe clamp DIN3015 supplier

Techi industrial Co.,ltd is stuaff standard hydraulic pipe clamp factory and manufacturer in CHINA, Our products cover heavy series pipe clamp, light series pipe clamp, twin series pipe clamp, U form clamp, Saddle clamp,plastic pipe clamp,polyamide pipe clamp. Pipe clamp plates surface treatment:Electroplating (galvanizing, nickel plating, gilding, etc.), painting, heat treatment, carbonitriding, etching, powder painting, polishing, electroplating, sandblasting, anodizing, passivation

STAUFF HEAVY SERIES HYDRAULIC PIPE CLAMPS are available in a single heavy (SH) unit two (2) bolt design, or a double heavy (DH) unit four (4) bolt design.

Heavy series hydraulic pipe clamp:Used for high pressure hydraulics and pipe diameter of 6–420 mm, male.
Clamp material: Polypropylene, aluminium, glass fibre reinforced polyamide and polypropylene with rubber grommet.

Pipe clamp range:

Light series clamp can be supplied in 8 series for normal mechanical stress,tube O.D 6 to 102mm.

(6~102mm)

Heavy series clamps can be supplied in 11 series for high mechanical stress,Tube O.D 6 to 508mm.( 6~508mm)

Twin pipe clamp series can be supplied in 5 series for normal mechanical stress,tube O.D 6 to 42mm.( 6~42mm)

Heavy Duty Hydraulic Pipe Clamp Single Hole size:

Heavy Duty Hydraulic Pipe Clamp Single Hole Package and production lines
