2-lug USA Type Air Hose Coupling Male End
1 Material: carbon steel,malleable steel
2 Size: 1/4″-2″
3 Users: Universal
4 Thread: Thread type is NPT
5 chicago coupling parts:male thread, female thread, hose tail
2-lug USA Type Air Hose Coupling Male End,Male Thread
Universal USA style couplings, also know as “Chicago Coupling”, are most commonly used on hose lines connecting pneumatic tools to a compressed air source. Sizes over I inch have a four lug design. chicago coupling parts:male thread,female thread, hose tail
| US TYPE AIR HOSE COUPLING | |
| Material: | malleable iron ,carbon steel |
| Type: | American type,European type,Australian type |
| Color: | yellow Zn plated or Silver Zn plate |
| Diameter: | 6.35mm,9.5mm,12.7mm,19mm,25.4mm,31.75mm,38.1mm,50.8mm. |
| Size: | 1/4″,3/8″,1/2″,3/4″,1″,11/2″,11/4″,2″. |
| Packing: | 25pcs in a small box,100pcs in a big box. |
| worker pressure: | 8KG |
| Air Universal Coupling – Air Hose coupling | |
| U.S. Type | |
| Items | Size |
| 2-lug Universal Male End | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| 2-lug Universal Female End | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| 2-lug Universal Hose End | 1/4″, 3/8″, 1/2″, 5/8″, 3/4″, 1″ |
| 4-lug Universal Female End | 1-1/4″, 1-1/2″, 2″ |
| 4-lug Universal Hose End | 1-1/4″, 1-1/2″, 2″ |
| 4-lug Universal Male End | 1-1/4″, 1-1/2″, 2″ |
| “Air king” Triple Connector | 3-ways |
| “Air king” Blank End | Blank End |
| “Air king” with Ferrules | 1/2″, 3/4″, 1″ |
| Washers for Universal Couplings | Two Lug/Four Lug |
| Safety Pin for Universal Couplings | Safety Pin |
| Europeam Type | |
| Universal Hose End | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| Universal Male BSPT End | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| Universal Female BSPT End | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| Hose End with Collar | 1/4″, 3/8″, 1/2″, 3/4″, 1″ |
| Australia Type | |
| Hose End | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
| Male End | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
| Female End | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
| Blank End | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
| Gasket | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
| Pin | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″ |
Air hose coupling Chicago Coupling manufacturer:
